A Thin, Oxidized Lead Finish Can Produce a Weak Solder Interface
Multiple components detached from circuit boards after assembly, leaving fractures at the component-lead-to-solder interface.
SEMEDSFracture-surface analysisMicrosectioningCoating-thickness measurementFailed-stock comparison
What the evidence preview establishes
Poor component-lead solderability created weak lead-to-solder interfaces. Contributing conditions included an unusually thin and nonuniform tin-lead finish, copper-tin intermetallic exposed at the surface, and substantial oxidation and chloride contamination.
Why this case matters
Evaluate detached components at the lead-to-solder interface and examine unsoldered stock. Finish thickness, uniformity, oxidation, contamination, and intermetallic breakthrough must be considered together when assessing solderability.
